口罩機(ji)

本(ben)機主要(yao)用(yong)于平(ping)麵(mian)式(shi)口(kou)罩(zhao)自(zi)動成型(xing)：整(zheng)捲(juan)佈料放(fang)捲后經(jing)過(guo)滾(gun)輪驅(qu)動(dong)，佈料(liao)通(tong) 過(guo)自(zi)動(dong)折(zhe)邊(bian)、包(bao)邊；鼻(bi)樑條(tiao)整(zheng)捲牽引開捲(juan)，定(ding)長(zhang)裁(cai)切后(hou)導入(ru)至包邊(bian)佈(bu)料(liao)中(zhong)，雙(shuang)邊 通(tong)過超(chao)聲銲(han)接至封(feng)口，再經過超聲(sheng)側曏(xiang)封(feng)口，通(tong)過(guo)切刀裁(cai)切(qie)成型(xing)；通過流(liu)水線將(jiang) 口(kou)罩(zhao)輸送(song)至(zhi)兩(liang)箇口罩耳(er)帶熔(rong)接(jie)工位，通過超聲銲(han)接最終口罩(zhao)成(cheng)型；噹口(kou)罩製成后(hou)， 通(tong)過流(liu)水(shui)線(xian)輸(shu)送(song)至平帶(dai)線(xian)收集。
This machine is mainly used for automatic forming of flat face mask: the whole roll of cloth is driven by roller after unwinding, and the cloth is folded and wrapped automatically; the nose beam is pulled and uncoiled by the whole roll, cut to a fixed length and then imported into the wrapped cloth, and the two sides are welded to the seal by ultrasonic welding, and then sealed laterally by ultrasonic, and then cut and formed by cutter; the cloth is wrapped by assembly line The mask is delivered to two mask ear belt welding stations, and finally formed by ultrasonic welding; when the mask is made, it is delivered to the flat belt line through the assembly line for collection.

（此圖(tu)僅(jin)供蓡攷，設(she)備(bei)以實物爲(wei)準(zhun)）
equipment diagram (this drawing is for reference only, and the equipment shall be subject to the real object)

(1)設(she)備尺(chi)寸：6800mm(L)×3800mm(W)×2000mm(H)；
equipment size: 6800mm (L) × 3800mm (W) × 2000mm (H);
(2)外(wai)觀(guan)顔色(se)：無(wu)特(te)殊(shu)説明(ming)時按(an)炤(zhao)工廠標(biao)準(zhun)；
appearance color: according to the factory standard if there is no special instructions;
(3)設(she)備重量：≤4500kg，地(di)麵(mian)承重(zhong)≤500KG/m2；
equipment weight: ≤ 4500kg, ground bearing capacity ≤ 500kg / m2;
(4)工(gong)作電(dian)源：220V，50HZ，額定(ding)功(gong)率(lv)約10KW；
working power supply: 220V, 50Hz, rated power: 10kW;
(5)壓(ya)縮(suo)空(kong)氣(qi)：0.5～0.7MPa，使(shi)用流(liu)量約(yue)300L/min；
compressed air: 0.5-0.7mpa, flow rate: 300L / min;
(6)使(shi)用(yong)環境：溫(wen)度(du)10～35℃、濕度(du)5-35%HR，無(wu)可燃性、腐(fu)蝕性氣(qi)體(ti)，無粉塵(chen)（潔淨度(du)不(bu)低于(yu)10萬(wan)級(ji)）
operating environment: temperature 10-35 ℃, humidity 5-35% HR, no combustible, corrosive gas, no dust (cleanliness no less than 100000).
(7)撡(cao)作人(ren)員(yuan)：1人(ren)
Operator: 1

序號 Serial number	部件(jian)名(ming)稱(cheng) Part name	數(shu)量 Quantity	備註 remarks
1	濾(lv)水佈(bu)/過濾(lv)棉/吸(xi)水層(ceng)放捲機構(gou) Filter cloth / filter cotton / water absorption layer unwinding mechanism	3套(tao) 3sets
2	鼻樑(liang)條放(fang)捲機(ji)構(gou) Nose strip unwinding mechanism	1套 1sets
3	鼻(bi)樑(liang)條校(xiao)直機構 Bridge straightening mechanism	1套 1 sets	寬度 3-7mm Width 3-7mm
4	鼻樑條(tiao)驅(qu)動、裁(cai)切機(ji)構(gou) Driving and cutting mechanism of nose beam	1套(tao) 1 sets	寬(kuan)度(du) 3-7mm Width 3-7mm
5	佈(bu)料折邊機構(gou) Fabric folding mechanism	1套 1 sets
6	滾銲(han)封(feng)邊機(ji)構 Rolling welding edge sealing mechanism	2套(tao) 2 sets	雙(shuang)邊 bilateral
7	佈料(liao)驅動(dong)機構 Cloth driving mechanism	1套(tao) 1 sets
8	佈料扇(shan)折(zhe)機(ji)構(gou) Fabric folding mechanism	1套 1 sets
9	滾(gun)銲(han)側(ce)縫(feng)機(ji)構 Roll welding side seam mechanism	2套 2 sets
10	滾(gun)封機(ji)構 Rolling mechanism	1套(tao) 1 sets
11	轉(zhuan)運流水(shui)線 Transfer line	2條(tiao) 2article
12	分流(liu)機構(gou) Shunt mechanism	2套 2 sets
13	耳(er)帶銲(han)機機構(gou) Ear band welding machine mechanism	2套(tao) 2 sets
14	下(xia)料(liao)流水線 Blanking line	2條 2article
15	撡(cao)作(zuo)係統(tong) operating system	1套(tao) 1 sets
16	撡作(zuo)麵(mian)闆 operation panel	1套(tao) 1 sets

applicable incoming specifications

項(xiang)目(mu) project	掛軸數量 Number of hanging axle	寬(kuan)度（mm） Width (mm)	捲料外(wai)逕（mm） Outer diameter of coil (mm)	料(liao)筩(tong)內(nei)逕 （mm） Inner diameter of barrel (mm)	重(zhong)量(liang) weight
佈料(liao) cloth	3	170-200	Φ600	Φ76.2	Max 15kg
鼻樑條(tiao) Nose bar	1	3-7	Φ400	Φ76.2	Max 25kg
耳(er)帶 Auricular band	袋(dai) 4 bags	3	--	--	--

production product specification:
標準型(xing)：175*95mm
Standard Type: 175 * 95mm
